Grooved Tee XGQT03
Housing Material: Ductile iron conforming to ASTM A-536 65-45-12
Coating: Paint, Epoxy, Galvanized, Dacromet
Groove: Conforming to international general requirements and can be connected with any brand grooved fittings and couplings.
Tel/WeChat：+86-15863655878
WhatsApp：++86 15863655878
Email:info@sdsxgy.com

PRODUCT DESCRIPTION

Nominal

Size

mm/in

Pipe OD.

mm/in

Working

Pressure

psi/Mpa

Dimensions

 L mm/in

Dimensions         L mm/in
S/RL/R

25

1

33.7

1.327

300 psi

2.07 Mpa

57

 2.24

57

 2.24

32

1¼

42.4

1.669

60

2.36

70

 2.36

40

1½

48.3

1.9

60

 2.36

70

 2.36

50

 2

60.3

 2.375

70

2.36

83

 3.267

65

 2½

73

2.875

76

3.00

95

3.74

65

2½

76.1

3

76

3.00

95

 3.74

80

3

88.9

3.5

86

  3.38

108

4.25

100

 4

108

4.25

92

3.622

127

 5

100

4

114.3

 4.5

101

3.98

127

 5

125

 5

133

5.25

122

4.80

140

5.5

125

 5

139.7

5.5

122

4.80

140

 5.5

125

 5

141.3

  5.563

122

4.80

140

5.5

150

 6

159

 6.25

120

 4.72

165

6.5

150

6

165.1

 6.5

140

 5.51

165

6.5

150

 6

168.3

 6.625

140

5.51

165

 6.5

200

 8

219.1

 8.625

175

6.88

197

 7.755

250

 10

273

 10.75

190

 7.48

/

300

12

323.9

12.750

245

 9.64

/
